Description
REBAR WIRE MESH WELDING MACHINE LYWM-3500
LYWM-3500 CNC welded steel mesh forming machine is a special equipment for steel welded mesh used in construction. This machine uses the principle of multi-electrode resistance spot welding to weld the longitudinal and transverse ribs of the steel bars into a firm mesh according to the set requirements. The raw materials of steel bars applicable to this machine can be cold-rolled ribbed steel bars, cold-rolled smooth steel bars or hot-rolled ribbed steel bars.
This machine is composed of welding mechanism, longitudinal rib, transverse rib feeding mechanism, mesh stepping mechanism, netting and conveying mechanism, pneumatic system, electrical control system, cooling system and other components.
Parameter name
unit
Numerical value
note
Welded steel bar diameter
mm
Ф8-Ф14
Max width of mesh
mm
3500
Mesh size
Longitudinal rib spacing
mm
100、150、200…
Cross bar spacing
mm
50--400steplessly adjustable
Welding point
point
34
Welding frequency
time/min
45--60
Max welding capacity
mm
￠14+￠12
Welding transformer capacity
KVA
160×17
Main transformer capacity
KVA
1000
power supply voltage
V
380
Current frequency
Hz
50
Pneumatic system working pressure
Mpa
≥0.8
Cooling water pressure
Mpa
0.2≤P<0.3
Compressed air consumption
M3/min
≥6
Longitudinal rebar feeding type
Straight bar、straightness≤3mm/1000mm
Cross bar discharging type
Straight bar、straightness≤3mm/1000mm
dimensions
m
L43×W4.5×H2.3
Total weight
T
~20
